Spaghetti Mat (Vinyl Cushion Mat / Safe Walkway Mat)
The TSB Spaghetti Mat is a heavy-duty, high-performance flooring solution designed for safety, durability, and maximum drainage across high-traffic industrial and commercial zones.
Crafted from virgin PVC, this mat features an open-loop structure that traps dirt, drains water efficiently, and offers superior slip resistance in both wet and dry conditions. Its backless construction allows easy cleaning and quick drying, while optional anti-slip backings ensure secure placement in sensitive work environments.
Available in multiple thicknesses, widths, and vibrant colors, the TSB Spaghetti Mat is ideal for construction walkways, warehouses, factories, kitchens, gyms, and other rugged applications requiring a strong, weather-resistant, and anti-fatigue surface.
Key Highlights:
- ➤ Open-loop vinyl structure for superior drainage & anti-slip performance
- ➤ Flame resistant, UV-stabilized, and non-toxic
- ➤ Withstands extreme temperatures: –25°C to +55°C
- ➤ Available with or without backing: spike, diamond, coin, brick
- ➤ Easy to clean, quick to install, and highly durable
Sustainability
TSB Cushion Mat™ products are 100% recyclable, and all backing variants are made using recycled PVC. We use environment-friendly virgin PVC compounds that are non-toxic and designed for long service life, reducing waste and environmental impact.
| Parameter | Options / Range |
| Thickness | 9–10 mm 12 mm 14 mm |
| Width | 1.0 m or 1.2 m |
| Length | 12 m or 15 m |
| Wire Diameter | 0.7–0.8 mm (Standard) |
| Backing Options |
With / Without Backing Anti-Slip Spike Anti-Skid Diamond Coin Backing Brick Backing |
| Colors Available | Green, Red, Grey, Blue, Black, Orange, Yellow Custom color on request |
| Material | Virgin PVC (Non-toxic, DOP-Free) |
| Properties | Flame Resistant, UV Stabilized, Recyclable, Pressure-Washable, Anti-Fungal |
| Temperature Range | –25°C to +55°C |
| Applications | Warehouses, Construction Walkways, Kitchens, Gyms, Industrial Flooring |
Sustainability
| Test | Standard | Result |
| Flammability | 16 CFR 1631 | PASS |
| Skid Resistance | ASTM F609 | PASS |
| BPA Chemical Test | HPLC-MS | BPA Not Detected |
Material Composition:
➤ 100% Virgin PVC
➤ Non-toxic, DOP-free
➤ UV Stabilized
➤ Fire Resistant
➤ Anti-Fungal
➤ Motor Oil Resistant
➤ Water & Weather Resistant
➤ Recyclable
TSB Cushion Mat – Traffic Rating Table
| Thickness | Backing Type | Traffic Category | Recommended Crossings / Day |
| 9 mm | Unbacked / Backed | Light Traffic | Up to 1,500 crossings/day |
| 12 mm | Unbacked / Backed | Medium Traffic | 1,500 – 3,000 crossings/day |
| 14 mm | Unbacked / Backed | Medium Traffic | 1,500 – 3,000 crossings/day |
| 16 mm | Unbacked / Backed | Heavy Traffic | 4,000 – 5,000 crossings/day |
| 16 mm SUMO | Unbacked / Backed | Very Heavy Traffic | 5,000+ crossings/day |
| 18 mm | Unbacked / Backed | Heavy Traffic | 4,000 – 5,000 crossings/day |
